Home > Products > Outdoor Fixed LED Display > P10 SMD3535 High Brightness Outdoor Full Color LED Video Wall Screen Panel for Advertising

P10 SMD3535 High Brightness Outdoor Full Color LED Video Wall Screen Panel for Advertising

Productivity:
10000sqm Per Moth
Place of Origin:
Made in China
Supply Ability:
10000sqm Per Moth
Certificate:
CE, RoHS, UL, CCC, ETL
  • Mr. Daniel Lin

Basic Info

Model No.:  LW-FO 10

Product Description

Model NO.: LW-FO 10 IP Rating: IP65 Pixel Configuration: 1R, 1G, 1B Average Power Consumption: 300W / m² Scanning Mode: 1/2 Scan Application: Advertising Pixel Configuration: 1r1g1b DIP346 Cabinet Size: 960X960X180 Brightness: More Than 7500CD/M2 Viewing Angle: H: 110 V: 60 Display Capability: Text, Graph and Video Trademark: LED World, OEM, ODM Specification: CE UL Rohs etc HS Code: 8528591090 Tube Chip Color: Full Color Pixel Pitch: 10mm Display Function: Video Display Pixel Density: 10000 dot / m² Display Type: LED Video Display Certification: CE, RoHS, UL, CCC, ETL Module Size: 320X160 Cabinet Weight: 36kg Viewing Distance: >16m Cabinet Material: Cold Rolled Steel or Aluminum IP Rate: Front IP65 Transport Package: Wooden/Case Carton Box or as Required Origin: Made in China Shenzhen led world co.,ltd is professional development manufacturing LED display system products , has a big promotion for in stock model.

Features:

1, Metal plate material cabinet at your will .

2, Fast delivery time, about 10 days.

3, Competitve prices witg good performance .

4, Long life-span.

5, More options according your site(The models as before ).

1 Items Parameter
2 NO.: LW-FO10
3 Pixel Pitch(mm) 10mm
4 Pixel configuration 1R1G1B/SMD3535
5 Pixel density 10000dots/sqm
6 Brightness  ≥7500cd/sqm
7 Module size(W*H) 320mm×160mm
8 Module Resolution (W*H) 32 dots x 16dots
9 Module weight 700g
10 Cabinet size (W*H) 960mm×960mm
11 Drive IC MBI5124
12 Drive mode 1/2scan
13 Viewing Angle(V/H) 140ºC
14 Grey Scale 65536 degree
15 Life time >100,000 Hours (80%)
17 MTBF >50,000 Hours
18 Operating Voltage AC110V/220V±10%
19 Screen Power Consumption Max: 10000w/sqm; Average:330w/sqm
20 Input Power Frequency 50/60Hz
21 Operating temperature  -30--60ºC
22 Humidity 10%-95%
23 Refresh Rate ≥1600HZ
24 Control Method Synchronized with computer monitor
25 Color Temperature 6500K-9500K
26 LED control system LINSN,Nova-star,Colorlight is selectable
27 Control Distance 100 m (no repeating); Optical fiber transmission: 500m- 15km
28 Accepting signal with video processor PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI
29 Systems Operating Platform Windows Xp / Windows 7 / windows 8 /8.1 / windows 10
After sales maintenance
1.Receive the cargo
Make sure the cargo in sealing condition and the cargo storage temperature
between - 30oC  and 60oC when you receive the goods from the customs
2. Install and use the product
Please adopt preheating model to light it up and keep 30% brightness for 0.5-2 hours when you use it . Keep it work 8 hours or above continually per day will be
 better. It will be better to use it at least once a week.
3. Cleaning
Ensure to use soft brush to clean the display surface and PROHIBIT any liquid
when doing cleaning.

Project case:
P10 SMD3535 High Brightness Outdoor Full Color LED Video Wall Screen Panel for Advertising
product detail:
P10 SMD3535 High Brightness Outdoor Full Color LED Video Wall Screen Panel for Advertising

Workshop:
P10 SMD3535 High Brightness Outdoor Full Color LED Video Wall Screen Panel for Advertising
Trade Terms
1. Package: Anti-shaking wooden package, Air flight case or Carton package
2. Payment: T/T, 40% deposits before production, 60% balance to be paid before delivery
3. Shipping freight are quoted under your requests
4. Shipping port: Shenzhen, China
5. Warranty time: 2years
6. Delivery time: 10-25 working days
