Home > Products > Outdoor Fixed LED Display > P10 Outdoor Full Color Fixed SMD3535 High Brightness LED Display Panel for Advertising

P10 Outdoor Full Color Fixed SMD3535 High Brightness LED Display Panel for Advertising

Productivity:
10000sqm Per Moth
Place of Origin:
Made in China
Supply Ability:
10000sqm Per Moth
Certificate:
CE, RoHS, UL, CCC, ETL
  • Mr. Daniel Lin

Basic Info

Model No.:  LW-FO 10

Product Description

Model NO.: LW-FO 10 IP Rating: IP65 Pixel Configuration: 1R, 1G, 1B Average Power Consumption: 300W / m² Scanning Mode: 1/2 Scan Application: Advertising Pixel Configuration: 1r1g1b DIP346 Cabinet Size: 960X960X180 Brightness: More Than 7500CD/M2 Viewing Angle: H: 110 V: 60 Display Capability: Text, Graph and Video Trademark: LED World, OEM, ODM Specification: CE UL Rohs etc HS Code: 8528591090 Tube Chip Color: Full Color Pixel Pitch: 10mm Display Function: Video Display Pixel Density: 10000 dot / m² Display Type: LED Video Display Certification: CE, RoHS, UL, CCC, ETL Module Size: 320X160 Cabinet Weight: 36kg Viewing Distance: >16m Cabinet Material: Cold Rolled Steel or Aluminum IP Rate: Front IP65 Transport Package: Wooden/Case Carton Box or as Required Origin: Made in China Wholesale Various High quality, High brightness SMD and DIP LED Module and led display with low price.

Features:

1, Metal plate material cabinet at your will .

2, Fast delivery time, about 10 days.

3, Competitve prices witg good performance .

4, Long life-span.

5, More options according your site(The models as before ).

1 Items Parameter
2 NO.: LW-FO10
3 Pixel Pitch(mm) 10mm
4 Pixel configuration 1R1G1B/SMD3535
5 Pixel density 10000dots/sqm
6 Brightness  ≥7500cd/sqm
7 Module size(W*H) 320mm×160mm
8 Module Resolution (W*H) 32 dots x 16dots
9 Module weight 700g
10 Cabinet size (W*H) 960mm×960mm
11 Drive IC MBI5124
12 Drive mode 1/2scan
13 Viewing Angle(V/H) 140ºC
14 Grey Scale 65536 degree
15 Life time >100,000 Hours (80%)
17 MTBF >50,000 Hours
18 Operating Voltage AC110V/220V±10%
19 Screen Power Consumption Max: 10000w/sqm; Average:330w/sqm
20 Input Power Frequency 50/60Hz
21 Operating temperature  -30--60ºC
22 Humidity 10%-95%
23 Refresh Rate ≥1600HZ
24 Control Method Synchronized with computer monitor
25 Color Temperature 6500K-9500K
26 LED control system LINSN,Nova-star,Colorlight is selectable
27 Control Distance 100 m (no repeating); Optical fiber transmission: 500m- 15km
28 Accepting signal with video processor PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI
29 Systems Operating Platform Windows Xp / Windows 7 / windows 8 /8.1 / windows 10
Applications:
Business Organizations super market, shopping mall, office building, industrial park, exclusive agency, chain shop, hotel, restaurant, travel agency, pharmacy, etc.
Financial Organizations banks, security company, insurance company, post office, hospital, school, etc.
Public Places subway, airport, train/bus station, gas station, toll station, bookstore, park, exhibition hall, stadium, museum, convention center, ticket center, HR market, lottery center, plaza, commercial building, parking lot, etc.
Entertainments movie theater, fitness hall, country club, night club, massage room, bar, cafe, Internet bar, beauty shop, golf course, casino, etc.
Packaging & Shipping
Standard Package: Veneer Case(Usually 4 cabinets in 1 veneer case)
Delivery time: 10-25 days after receiving the deposit
After sales maintenance
1.Receive the cargo
Make sure the cargo in sealing condition and the cargo storage temperature
between - 30oC  and 60oC when you receive the goods from the customs
2. Install and use the product
Please adopt preheating model to light it up and keep 30% brightness for 0.5-2 hours when you use it . Keep it work 8 hours or above continually per day will be
 better. It will be better to use it at least once a week.
3. Cleaning
Ensure to use soft brush to clean the display surface and PROHIBIT any liquid
when doing cleaning.

Project case:
P10 Outdoor Full Color Fixed SMD3535 High Brightness LED Display Panel for Advertising
product detail:
P10 Outdoor Full Color Fixed SMD3535 High Brightness LED Display Panel for Advertising

Workshop:
P10 Outdoor Full Color Fixed SMD3535 High Brightness LED Display Panel for Advertising
Features of the Our LED Display:
*Quick assembly model, 2 persons are able to assemble 20sqm within one hour
*Light weight, for indoor application, only 35-38kg/sqm, for outdoor application, only 45-55kg/sqm
*Weatherproof to IP65 standards
*High resolution images
*Easily configured for various size and aspect ratios
*Wide viewing angle
*Brightness is adjustable depends on environment
*Compatible with inputs: S-Video, Composite, YUV, RBG, SDI, HKSDI, Data SVI up to SXGA


Contact us if you need more details on LED Display Screen. We are ready to answer your questions on packaging, logistics, certification or any other aspects about LED Display、LED Screen. If these products fail to match your need, please contact us and we would like to provide relevant information.
