Outdoor High Brightness P10 Full Color Fixed LED Digital/Electronic Billboard for Advertising

Model NO.: LW-FO 10 IP Rating: IP65 Pixel Configuration: 1R, 1G, 1B Average Power Consumption: 300W / m² Scanning Mode: 1/2 Scan Application: Advertising Pixel Configuration: 1r1g1b DIP346 Cabinet Size: 960X960X180 Brightness: More Than 7500CD/M2 Viewing Angle: H: 110 V: 60 Display Capability: Text, Graph and Video Trademark: LED World, OEM, ODM Specification: CE UL Rohs etc HS Code: 8528591090 Tube Chip Color: Full Color Pixel Pitch: 10mm Display Function: Video Display Pixel Density: 10000 dot / m² Display Type: LED Video Display Certification: CE, RoHS, UL, CCC, ETL Module Size: 320X160 Cabinet Weight: 36kg Viewing Distance: >16m Cabinet Material: Cold Rolled Steel or Aluminum IP Rate: Front IP65 Transport Package: Wooden/Case Carton Box or as Required Origin: Made in China All in to strive for the best service + the top quality + the reasonable price:
1.quick response: replying inquiry within 12hrs
2.on time delivery + patient after-sales service
3.manufacturer: over 8 years
4.quality guarantee: CE, RoHS, FCC, IP105, ISO9001 + 100% testing before shipping.

Features:

1, Metal plate material cabinet at your will .

2, Fast delivery time, about 10 days.

3, Competitve prices witg good performance .

4, Long life-span.

5, More options according your site(The models as before ).


1	Items	Parameter
2	NO.:	LW-FO10
3	Pixel Pitch(mm)	10mm
4	Pixel configuration	1R1G1B/SMD3535
5	Pixel density	10000dots/sqm
6	Brightness	≥7500cd/sqm
7	Module size(W*H)	320mm×160mm
8	Module Resolution (W*H)	32 dots x 16dots
9	Module weight	700g
10	Cabinet size (W*H)	960mm×960mm
11	Drive IC	MBI5124
12	Drive mode	1/2scan
13	Viewing Angle(V/H)	140ºC
14	Grey Scale	65536 degree
15	Life time	>100,000 Hours (80%)
17	MTBF	>50,000 Hours
18	Operating Voltage	AC110V/220V±10%
19	Screen Power Consumption	Max: 10000w/sqm; Average:330w/sqm
20	Input Power Frequency	50/60Hz
21	Operating temperature	-30--60ºC
22	Humidity	10%-95%
23	Refresh Rate	≥1600HZ
24	Control Method	Synchronized with computer monitor
25	Color Temperature	6500K-9500K
26	LED control system	LINSN,Nova-star,Colorlight is selectable
27	Control Distance	100 m (no repeating); Optical fiber transmission: 500m- 15km
28	Accepting signal with video processor	PAL/NTSC/SECAM,S-Video;VGA;RGB;Composite Video;SDI
29	Systems Operating Platform	Windows Xp / Windows 7 / windows 8 /8.1 / windows 10

Applications:

Business Organizations	super market, shopping mall, office building, industrial park, exclusive agency, chain shop, hotel, restaurant, travel agency, pharmacy, etc.
Financial Organizations	banks, security company, insurance company, post office, hospital, school, etc.
Public Places	subway, airport, train/bus station, gas station, toll station, bookstore, park, exhibition hall, stadium, museum, convention center, ticket center, HR market, lottery center, plaza, commercial building, parking lot, etc.
Entertainments	movie theater, fitness hall, country club, night club, massage room, bar, cafe, Internet bar, beauty shop, golf course, casino, etc.

Packaging & Shipping
Standard Package: Veneer Case(Usually 4 cabinets in 1 veneer case)
Delivery time: 10-25 days after receiving the deposit
After sales maintenance
1.Receive the cargo
Make sure the cargo in sealing condition and the cargo storage temperature
between - 30oC  and 60oC when you receive the goods from the customs
2. Install and use the product
Please adopt preheating model to light it up and keep 30% brightness for 0.5-2 hours when you use it . Keep it work 8 hours or above continually per day will be
 better. It will be better to use it at least once a week.
3. Cleaning
Ensure to use soft brush to clean the display surface and PROHIBIT any liquid
when doing cleaning.

Project case:

product detail:


Workshop:

After-sales Service
1: Warranty: 2 years.
2: Service time: 24 hours*7 days.
3: All of our Led Display have proceeded aging test before shipment,
And we guarantee to use our products safety.
4: All the LED display are inspected before shipment, If any problems happen, do not hesitate to contact with us, our team will do our best to solve for customer within 48hours.



Contact us if you need more details on Led Display Screen. We are ready to answer your questions on packaging, logistics, certification or any other aspects about LED Display、Led Screen. If these products fail to match your need, please contact us and we would like to provide relevant information.

Product Categories : Outdoor Fixed LED Display
